Part number: 1B31S LT Manufacturer SKU: 51468
For current pricing and to place an order please contact your Ellsworth Customer Service Representative.
Call Us Contact Customer Service at +91 011 45566223-5。
Live Chat Speak with one of our Technical Service Personnel.
Request a Quote Submit a quote request and a Sales Representative will contact you.
Send an Email We will respond within 1 business day.
-
DescriptionHumiSeal® 1B31S Acrylic Conformal Coating is a one component, fast curing acrylic conformal coating that is used for circuit assemblies and can be easily repaired. It offers excellent flexibility, moisture and environmental protection, and fluoresces under UV light to aid inspection. It can be applied by spraying, brushing, or dipping methods. 1 L Can.
-
Product Details
Typical Use: Acrylic coating providing excellent moisture and environmental protection for printed circuit assemblies. Chemical Composition: Acrylic Components: 1 part Cure System: Room Temperature/Heat Cure Time: 24h @ room temperature; 30min @ 76 °C Flash Point: -1 °C Key Specifications: HumiSeal 1B31S is in full compliance with the RoHS Directive (Directive 2002/95/EC). Specific Gravity: 0.88 Tack Free Time: 10min Viscosity: 200 ± 15 -
SDS / TDS
